Mini Terra Prime is Kaleidescape’s new miniature, silent solid-state server. As part of the Terra Prime server line, Mini Terra Prime delivers fast downloads, high-performance playback, and ample storage. Terra Prime stores movies, TV series, and concerts on internal hard drives. Content stored is played back on Strato movie players.
Features
Stores ~125 Kaleidescape high-bitrate 4K movies
Download a 4K movie in as little as 4 minutes
Serves up to 25 simultaneous Kaleidescape high-bitrate 4K movies
All movies are stored securely and protected by cloud backup
Up to 4 Terra servers can be combined for more storage
Specifications
CASE
Black painted steel
DOWNLOAD SPEED
Downloads Kaleidescape high-bitrate 4K movies in as little as 4 minutes over a 2.5 gigabit Ethernet connection
SIMULTANEOUS PLAYBACKS
Serves simultaneous playbacks of Kaleidescape high-bitrate 4K movies to 25 network-attached Strato movie players
NETWORK
Ethernet cable link required
Capable of 2.5 Gigabit (recommended) and 1 Gigabit (minimum)
OTHER CONNECTION
USB 3.0 (reserved)
DIMENSIONS
6.4in x 1.1in x 6.4in (W x H x D) (16.3cm x 3cm x 16.3cm)
WEIGHT
1.7lb (0.77kg)
POWER
Max consumption: 23W
Typical: 15W
External power adapter with detachable line cord: 100-240VAC to 12VDC @ 5A, 60W, isolated ground
ENVIRONMENT
Operating: 41 to 95°F (5 to 35°C)
Storage: -4 to 140°F (-20 to 60°C)
Relative humidity: 20 to 80% (operation) 5 to 90% (storage)
Maximum operating altitude: 10,000ft (3,048m)
Heat output: 78.5 BTU/hr (23W) max
Airflow: Place in an area with circulating air.
FAN NOISE
Silent (no internal fan)
VENTILATION
Front: Minimum 1in (2.5cm)
Rear: Minimum 2in (5cm)
Top: Minimum 0.25in (0.64cm), to allow for convection cooling
MOUNTS (sold separately)
Rack shelf with faceplates is available for mounting 1 or 2 Mini Terra Prime servers, Strato E or Strato M players in a 19in rack, 1U space (centered or side-by-side)
Wall mount available for mounting behind TV displays (note ventilation requirements)
CERTIFICATIONS
CSA 62368-1
IEC 62368-1
FCC CLASS B
CE
AU/NZ Regulatory Compliance Mark (RCM)
RoHS Compliant
STORAGE
8TB SSD: 2x 4TB solid-state drives (available storage for approximately 125 Kaleidescape high-bitrate movies, 216 HD movies, or 1,200 SD movies)
MEDIA
Kaleidescape movie store downloads: 4K Dolby Vision, 4K HDR10, 4K SDR, HD, and SD quality
